SWS
2
Fan heater SWS
1. Fan heater SWS
2. Mounting brackets SWB
3. Basic filter SWSFT
4. Filter section, deep-pleated
bagfilter EU3 SWF
5. Return air intake SWD
6. Extra air director SWLR
7. Drip tray SWST
1
2
3
4
5
7
6
Accessories
Type Description
SWLR1 Extra air director SWS12
SWLR2 Extra air director SWS22
SWLR3 Extra air director SWS32/33
SWSFT02 Basic filter SWS02
SWSFT1 Basic filter SWS12
SWSFT2 Basic filter SWS22
SWSFT3 Basic filter SWS32/SWS33
SWST02 Drip tray SWS02
SWST1 Drip tray SWS12
SWST2 Drip tray SWS22
SWST3 Drip tray SWS32/33
Type Description
SWB0 Mounting brackets SWS02
SWB1 Mounting brackets SWS12
SWB2 Mounting brackets SWS22
SWB3 Mounting brackets SWS32/SWS33
SWF1 Filter section SWS12
SWF2 Filter section SWS22
SWF3 Filter section SWS32/SWS33
SWD1 Return air intake SWS12
SWD2 Return air intake SWS22
SWD3 Return air intake SWS32/SWS33
SWEF1 Extra filter cassette EU3 SWS12
SWEF2 Extra filter cassette EU3 SWS22
SWEF3 Extra filter cassette EU3 SWS32/SWS33
SWST
SWB SWF SWD SWSFTSWLR
