Systemair SWS33 [3/18] Dimensions
![Systemair SWS33 [3/18] Dimensions](/views2/1714702/page3/bg3.png)
SWS
3
B
C
D
E
F
A
Inlet
Outlet
G
H
I
J
K
ø
Type A
[mm]
B
[mm]
C
[mm]
D
[mm]
E
[mm]
F
[mm]
G
[mm]
H
[mm]
I
[mm]
J
[mm]
K
[mm]
Ø
[mm]
SWS02
470 520 210 50 95 40 70 40 390 65 260 22
SWS12
545 540 215 60 95 40 70 40 465 65 260 22
SWS22
675 690 215 60 100 45 70 45 585 70 400 28
SWS32(3)
SWS33(3)
800 830 315 35 100 45 70 45 710 70 530 28
Dimensions
Type A
[mm]
B
[mm]
C
[mm]
D
[mm]
SWB0 195 405 235 10
SWB1 195 470 300 10
SWB2 250 580 410 10
SWB3 335 700 530 10
Type E
[mm]
F
[mm]
G
[mm]
H
[mm]
I
[mm]
SWF1 466 492 470 444 524
SWF2 616 602 580 594 524
SWF3 746 722 700 724 524
Type J
[mm]
K
[mm]
L
[mm]
M
[mm]
SWD1 466 492 470 444
SWD2 616 602 580 594
SWD3 746 722 700 724
M
N
(1
8)
Drip tray, SWST
Type M
[mm]
N
[mm]
SWST02 518 218
SWST1 538 213
SWST2 691 217
SWST3 828 313
J
M
L
K
122
Return air intake, SWD
Filter section, SWF
Mounting brackets SWB
A
B
C
D
D
I
288
42,
3
G
H
E
F
50
ø20
