PLANET IPX-2000 user’s manual

29 of 51

separated by commas. Use Remove button

and Remove all button accordingly when

some forwardings are no longer required.

3.10.2 Analog Phone

Connect an analog phone to a FXS port and configure the properties of the port as detailed in

Table 4-3-3.

Table 4-3-3 FXS Extension Configuration Settings

Field Description

POTS port FXS port index

Extension number A unique line number composed of digits

only, e.g. 101; 32 digits maximum.

Pickup group The pickup group the extension belongs to.

Unavailable timeout Timeout for ringing before a call is answered.

User

Select the user this extension associates with.

F There may not be appropriate users to

select initially. One can come back later once

the expected user has been added.

Voicemail Select enable to allocate voicemail account for

the extension.

Voicemail PIN PIN to access voicemails. This is mandatory if

above voicemail option is enabled.

Language Preferred language for system instructions

heard from the extension.

Input/Output gain Voice amplification or attenuation in dB scale

to adjust input/output volume.

Unconditional call forward (Optional) Check voicemail as default

destination or enter a number to which

incoming calls are forwarded unconditionally.

The number could be an extension or a PSTN

number with appropriate outbound prefix.

Unavailable call forward (Optional) Enter a number to which incoming

calls are forwarded when not answered. The

number could be an extension or a PSTN

number with appropriate outbound prefix.

Line in use forward (Optional) Enter a number to which incoming

calls are forwarded when the extension is

busy. The number could be an extension or a

PSTN number with appropriate outbound

prefix.

Please refer to 3.9 for details.
