PLANET IPX-2000 user’s manual

31 of 51

Management page. IP PBX service must be reloaded to activate changes.

3.11.1 Add Route

• Click <Add new> button from the left panel.

• Enter settings shown in Table 4-4-2.

• Click Save button.

The newly added route should be displayed in Routes panel on the left side.

3.11.2 Edit Route

• Click the link of the route to edit from the Routes panel.

• Edit settings shown on the right side.

• Click Save button.

3.11.3 Delete Route

• Click the link of the route to delete from the Routes panel.

• Click Delete button.

The deleted route shall disappear from the Routes panel.

Table 4-4-2 Route Configuration Settings

Field Description

Route ID A unique ID containing alphabets, numbers,

and underscore only without spaces; 32

characters maximum.

Description Arbitrary description info.

Destination number pattern A destination number pattern consisting of

digits, digit set, and wildcard characters, e.g.

9NXXXXXX matches any 7-digit called

number starting from a digit larger or equal to

2 and with an extra prefix digit 9.

Number of stripped digits Number of leading digits to be stripped from

the original dialed number when matches this

route. Using 9NXXXXXX as an example

route pattern with number of stripped digits

equal to 1, dialing 95270001 will be stripped

to be 5270001 when it actually got dialed out.

Prefix A sequence of digits to be prefixed to the final

dialed number after stripping. Using

9NXXXXXX as an example route pattern

with number of stripped digits equal to 1 and

prefix 1408, dialing 95270001 will be

14085270001 when it actually got dialed out.

A special prefix character “w” could be used

for PSTN trunks to pause 0.5 second during
