PLANET IPX-2000 user’s manual

50 of 51

Figure 5-2

Configuration steps in B-HQ:

1. Create usergroups staff, utility, and ext-all.

2. Include staff and utility in the Reachable usergroup of ext-all.

3. Create a user account for each staff and assign it to usergroup staff.

4. Create an additional user account public and assign it to usergroup utility.

5. Create a device for each physical phone and designate an extension.

6. Assign extensions of staff phones to corresponding users.

7. Assign all extensions of utility phones to share the same user public.

8. Create a route pstn with pattern 9Z. with number of digits stripped 1, no prefix.

9. Create a route pstn-br with pattern 90118621. with number of digits stripped 8,

prefix 9.

10. Create a route ext-br with pattern 2XX and number of digits stripped 0, no prefix.

11. Create a routegroup pstn-out containing route pstn only.

12. Create a routegroup to-br containing routes pstn-br and ext-br.

13. Create a PSTN trunk with ID 1, port 1-4, choose pstn-out as Outbound routegroup,

leave DID unchecked, and select ext-all as the Usergroup of privilege.

14. Create a dynamic peer SIP trunk with ID 100; password hq-secret; choose to-br as

Outbound routegroup, leave DID unchecked, and select staff as the Usergroup of

privilege.

15. Return to usergroup configuration. For usergroup staff, include SIP trunk 100, PSTN

LAN

Internet

modem

PSTN

LAN

modem

PSTN

B-HQ

B-BR
