PLANET IPX-2000 user’s manual

6 of 51

1. AC Power 110/220 Volt, 60 Hz

2. FXO ports 4 ports per daughter card, numbered from right to the left.

The rightmost port at slot 0 is port 1 and the leftmost port at

slot 1 (if installed) is port 8. FXO ports are to be connected

to FXS jacks on wall or analog PBX using RJ-11 cables.

3. USB ports 2 external ports with compliance to USB 1.1/2.0. Plug in a

USB hard drive for CDR/voicemail backup from the internal

storage.

4. WAN Connect to a broadband modem or a WAN router.

5. LAN Connect to a LAN switch.
