Planet VIP-161W [45/72] Account setting

TCP

TCP guarantees delivery of data and also guarantees that packets will be

delivered in the same order in which they were sent

SIP Time Interval

SIP time interval in milliseconds. The default setting is 500 m-sec

Timeout for Invite

INVITE message timeout value. Assigns a value 1 to 100, default setting

is 12 seconds. It denotes if an INVITE request was sent, and a response

is not received from the remote site within the allotted time. The present

request will be dropped and a new connection request will be initiated

Timeout for Ring Back

Timeout value for dropping a call after receiving 180 responses. Ring

back is an intermittent audio tone that a caller in a telephone system

hears after dialing a number, when the distant end of the circuit is

receiving a ringing signal. It can be generated by the servicing switch of

either the called party or the calling party. It is not generated by the called

instrument. The default setting is 180 seconds

Timeout for Release

BYE message timeout value. Assigns a time interval 1 to 4, default setting

is 4 seconds

Registration Retry count

Assigns a value 1 to 65535, To set the retry count for keepalive

retransmission, use the retry keepalive command in SIP user agent

configuration mode. To restore the retry count to the default value for

keepalive retransmission, use the no form of this command

SIP User Agent name

If specified, is the user-agent name to be used in a REGISTER request. If

not specified, the value in “SIP User Agent Name” will be used for

Account Setting

There are two ports can be setup for SIP account.

Phone Number

Assigns Phone number for the first port, maximum 15 digits. Do not contain

any special characters or spaces. E.g. if you want to enter the number

+886 2 1234-5678, then it should be 886212345678

Display Name

This text message will be sent between the callee and caller and will show

on LCD panel for general using

Authentication User Name

User name for authentication. Maximum 36 characters

Authentication Password

User password for authentication. Maximum 24 characters
