3
GB
Technical data
Model
WDG 862
Dimensions
width 59.5 cm
height 85 cm
depth 60,5 cm
Capacity
from 1 to 8 kg for the wash
programme
from 1 to 6 kg for the drying
programme
Electrical
connections
please refer to the technical
data plate fixed to the machine
Water con-
nections
maximum pressure
1 MPa (10 bar)
minimum pressure
0.05 MPa (0.5 bar)
drum capacity 62 litres
Spin speed
up to 1200 rotations per
minute
Energy ra-
ted
programmes
according to
regulation
EN 50229
Wash: programme 4; tem-
perature 60°C; using a load
of 8 kg.
Drying: the smaller load
must be dried by selecting
the “A1” (IRON) dryness le-
vel. The load must consist of
2 sheets, 1 pillowcase and 1
hand towel;
the remainder of the load must
be dried by selecting the “A4”
(EXTRA) dryness level.
This appliance conforms to
the following EC Directives:
- 2004/108/EC (Electromagne-
tic Compatibility)
- 2006/95/EC (Low Voltage)
- 2002/96/EC
65 - 100 cm
Connecting the drain hose
Connect the drain
hose, without bending
it, to a drainage duct
or a wall drain located
at a height between
65 and 100 cm from
the floor;
alternatively, rest
it on the side of
a washbasin or
bathtub, fastening
the duct supplied to
the tap (see figure).
The free end of the
hose should not be
underwater.
! We advise against the use of hose
extensions; if it is absolutely necessary, the
extension must have the same diameter as the
original hose and must not exceed 150 cm in
length.
Electrical connections
Before plugging the appliance into the
electricity socket, make sure that:
• the socket is earthed and complies with all
applicable laws;
• the socket is able to withstand the maximum
power load of the appliance as indicated on
the Technical Data Plate fixed on the machine;
• the power supply voltage falls within the
values indicated on the Technical Data Plate
fixed on the machine;
• the socket is compatible with the plug of the
washer-dryer. If this is not the case, replace
the socket or the plug.
! The washer-dryer must not be installed
outdoors, even in covered areas. It is extremely
dangerous to leave the appliance exposed to
rain, storms and other weather conditions.
! When the washer-dryer has been installed, the
electricity socket must be within easy reach.
! Do not use extension cords or multiple sockets.
! The cable should not be bent or compressed.
! The power supply cable must only be
replaced by authorised technicians.
Warning! The company shall not be held
responsible in the event that these regulations
are not respected.
The first wash cycle
Once the appliance has been installed, and
before you use it for the first time, run a wash
cycle with detergent and no laundry, using the
wash cycle “Auto Clean”.
