14
8-11 THE OUTDOOR UNIT FAN DOES NOT
ROTATE
• During operation.
The speed of the fan is controlled in order to opti-
mize product operation.
8-12 THE DISPLAY SHOWS
“”
• This is the case immediately after the main
power supply switch is turned on and means
that the remote controller is in normal condi-
tion. This continues for 1 minute.
8-13 THE COMPRESSOR OR FAN IN THE
OUTDOOR UNIT DOES NOT STOP
• This is to prevent oil and refrigerant from
remaining in the compressor. The unit will
stop after 5 to 10 minutes.
8-14 THE INSIDE OF OUTDOOR UNIT IS
WARM EVEN WHEN THE UNIT HAS
STOPPED
• This is because the crankcase heater is warm-
ing the compressor so that the compressor
can start smoothly.
8-15 IT STOPS SOMETIMES
• The remote controller display reads “U4” and
“U5” and stops but then restarts after a few
minutes.
This is because the remote control is intercepting
noise from electrical appliances other than the air
conditioner, and this prevents communication
between the units, causing them to stop.
Operation automatically restarts when the noise
goes away.
8-16 HOT AIR IS EMITTED EVEN THOUGH
THE UNIT IS STOPPED
• Hot air can be felt when the unit is stopped.
Several different indoor units are being run on the
same system, so if another unit is running, some
refrigerant will still flow through the unit.
8-17 DOES NOT COOL VERY WELL
• Program dry operation.
Program dry operation is designed to lower the
room temperature as little as possible.
Refer to page 9.
9. TROUBLE SHOOTING
If one of the following malfunctions occurs, take
the measures shown below and contact your
Daikin dealer.
WARNING
Stop operation and shut off the power if any-
thing unusual occurs (burning smells, etc.)
Leaving the unit running under such circum-
stances may cause breakage, electrical shock, or
fire.
Contact your dealer.
• If a safety device such as a fuse, a breaker or an
earth leakage breaker frequently actuates;
Measure: Do not turn on the main power switch.
• If the ON/OFF switch does not properly work;
Measure: Turn off the main power switch.
• If water leaks from unit;
Measure: Stop the operation.
• The operation mode selector button does not
work well.
Turn off the power.
• If the display
“”
, the unit number and the
operation lamp flash and the malfunction code
appears; (Refer to figure 12)
1. Inspection display
2. Indoor unit number in which a malfunction
occurs
3. Operation lamp
4. Malfunction code
Measure: Notify your Daikin dealer and report the
malfunction code.
If the system does not properly operate except
for the above mentioned cases and none of the
above mentioned malfunctions is evident, inves-
tigate the system according to the following pro-
cedures.
If it is impossible to fix the problem yourself after
checking all the above items, contact your
dealer.
Let him know the symptoms, system name, and
model name.
1. If the system does not operate at all;
• Check if there is a power failure.
Wait until power is restored. If power failure
occurs during operation, the system automati-
cally restarts immediately after the power supply
is recovered.
TEST
01_EN_3P161360-3D.fm Page 14 Thursday, April 13, 2006 9:46 AM
