Ariston WMSD 723B [8/60] Running a wash cycle

Running a wash cycle

1. SWITCH THE MACHINE ON. Press the On/Off

button ; the text POWER ON will appear on the

display and the START/PAUSE indicator light will flash

slowly in a green colour.

2. LOAD THE LAUNDRY. Open the porthole door.

Load the laundry, making sure you do not exceed

the maximum load value indicated in the table of

programmes on the following page.

3. MEASURE OUT THE DETERGENT. Open the

detergent dispenser drawer and pour the detergent into

the relevant compartments as described in “Detergents

and laundry”.

4. CLOSE THE DOOR.

5. SELECT THE WASH CYCLE. Press one of the WASH

CYCLE SELECTOR buttons to select the required wash

cycle; the name of the wash cycle will appear on the

display. A temperature and spin speed is set for each

wash cycle; these may be adjusted. The duration of the

cycle will appear on the display.

6. CUSTOMISE THE WASH CYCLE. Use the relevant

buttons:

Modifying the temperature and/or spin

speed. The machine automatically selects the

maximum temperature and spin speed set for the

selected wash cycle; these values cannot therefore

be increased. The temperature can be decreased by

pressing the button, until the cold wash “OFF”

setting is reached. The spin speed may be progressively

reduced by pressing the button, until it is completely

excluded (the “OFF” setting). If these buttons are

pressed again, the maximum values are restored.

! Exception: if the

(60°)

(1st press of the button)

programme is selected, the temperature can be

increased up to a value of 90°C.

Setting a delayed start.

To set a delayed start for the selected programme,

press the corresponding button repeatedly until the

required delay period has been reached. When this

option is enabled, the symbol lights up on the

display. To remove the delayed start function press the

button until the text “OFF” appears on the display.

Set the desired wash intensity.

Option makes it possible to optimise washing

based on the level of soil in the fabrics and on desired

wash cycle intensity.

Select the wash programme: the cycle will be

automatically set to “Normal” as optimised for garments

with an average level of soil (this setting is not applicable to

the “Wool” cycle, which is automatically set to “Delicate”).

For heavily-soiled garments press button until

the “Super Wash” level is reached. This level ensures

a high-performance wash due to a larger quantity of

water used in the initial phase of the cycle and due to

increased drum rotation. It is useful when removing the

most stubborn stains.

It can be used with or without bleach. If you wish to

bleach the items insert the additional compartment

(4) into compartment 1. When pouring the bleach, be

careful not to exceed the “max” level marked on the

central pivot (see figure pag. 10).

For lightly-soiled garments or a more delicate treatment

of the fabrics, press button until the “Delicate” level

is reached.

The cycle will reduce the drum rotation to ensure

washing results are perfect for delicate garments.

Set the rinse type.

Option makes it possible to select the desired rinse

type for sensitive skin. Press the button once for the

“Extra Rinse” level, which makes it possible to select

an additional rinse after the standard cycle rinse and

remove all traces of detergent. Press the button again

for the “Sensitive Skin” level, which makes it possible to

select two additional rinses to the standard cycle rinses; it

is recommended for very sensitive skin. Press the button

for the third time for the “Anti allergy Rinse” level, which

makes it possible to select three additional rinses to the

standard cycle rinses and remove major allergens such as

pollen, mites, cat and dog hair. Press the button again to

go back to the “Normal Rinse” rinse type. If the current

adjustment can be neither set nor changed, the display will

show “Not allowed”.

Modifying the cycle settings.

• Press the button to enable the function; the indicator

light corresponding to the button will switch on.

• Press the button again to disable the function; the

indicator light will switch off.

! If the selected function is not compatible with the

programmed wash cycle, the indicator light will flash

and the function will not be activated.

! If the selected function is not compatible with

another function which has been selected previously,

the indicator light corresponding to the first function

selected will flash and only the second function will

be activated; the indicator light corresponding to the

enabled function will remain lit.

! The functions may affect the recommended load value

and/or the duration of the cycle.

7. START THE PROGRAMME. Press the START/PAUSE

button. The corresponding indicator light will become

green, remaining lit in a fixed manner, and the door will be

locked (the DOOR LOCKED symbol will be on). During

the wash cycle, the name of the phase in progress will

appear on the display. To change a wash cycle while

it is in progress, pause the washing machine using the

START/PAUSE button (the START/PAUSE indicator light

will flash slowly in an orange colour); then select the

desired cycle and press the START/PAUSE button again.

To open the door while a cycle is in progress, press

the START/PAUSE button; if the DOOR LOCKED

symbol is switched off the door may be opened. Press

the START/PAUSE button again to restart the wash cycle

from the point at which it was interrupted.

8. THE END OF THE WASH CYCLE. This will be

indicated by the text “END OF CYCLE” on the display;

when the DOOR LOCKED symbol switches off

the door may be opened. Open the door, unload the

laundry and switch off the machine.

! If you wish to cancel a cycle which has already begun,

press and hold the button. The cycle will be stopped

and the machine will switch off.

Ariston WMSD 723B [8/60] Running a wash cycle
