6
1.2.4 System Requirements
§ Pentium-class 90 MHz or higher
§ Minimum 32 MB RAM
§ USB-ready PC
§ Windows 98SE, ME, 2000 and XP
§ CD-ROM Drive (for installing driver and Encryption Utility)
1.3 Specification
Product Powerline Ethernet Bridge
Powerline USB Adapter
Model PL-104E PL-104U
Standards
HomePlug 1.0
IEEE 802.3 10Base-T
HomePlug 1.0
USB 1.1
Ports
One Powerline Port
One 10Mbps Ethernet
RJ-45 port
One Powerline port
One USB type B jack
Speed
LAN: 10Mbps
Powerline: 14Mbps (actual
throughput is about 6Mbps)
USB: 12Mbps
Powerline: 14Mbps (actual
throughput is about 6Mbps)
Powerline
Frequency Band
4.3MHz to 20.9MHz
Encryption 56-bit DES with Key configuration software
Dimension 65 x 93 x 78 mm
Weighy 230g 110g
Certifications FCC Class B, CE
Operating Temp. 0 ~ 50 degree C
Storage Temp. -20 ~ 70 degree C
Operating Humidity
10~90% non-condensing
Storage Humidity 5~95% non-condensing
