Specifications Si34-804
20 Specifications
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
Model Name (Combination Unit) RXQ38PAY1 RXQ40PAY1
Model Name (Independent Unit) RXQ8PAY1+RXQ12PAY1+RXQ18PAY1 RXQ8PAY1+RXQ16PAY1+RXQ16PAY1
★1 Cooling Capacity (19.5°CWB)
kcal / h 91,200 97,200
Btu / h 362,000 386,000
kW 106 113
★2 Cooling Capacity (19.0°CWB) kW 105 112
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm (1680×930×765)+(1680×1240×765)+(1680×1240×765) (1680×930×765)+(1680×1240×765)+(1680×1240×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h (16.90)+(13.34+10.53)+(16.90+10.53+10.53) (16.90)+(13.34+10.53+10.53)+(13.34+10.53+10.53)
Number of Revolutions r.p.m (7980)+(6300, 2900)+(7980, 2900, 2900) (7980)+(6300, 2900, 2900)+(6300, 2900, 2900)
Motor Output×Number
of Units
kW (3.6×1)+((1.8+4.5)×1)+((4.3+4.5+4.5)×1) (3.6×1)+((2.7+4.5+4.5)×1)+((2.7+4.5+4.5)×1)
Starting Method Soft Start Soft Start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW (0.75×1)+(0.35×2)+(0.75×2) (0.75×1)+(0.35×2)+(0.35×2)
Airflow Rate m³/min 180+233+239 180+233+233
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm
φ
19.1 (Brazing Connection)
φ
19.1 (Brazing Connection)
Gas Pipe mm
φ
41.3 (Brazing Connection)
φ
41.3 (Brazing Connection)
Product Mass (Machine Weight) kg 205+285+341 205+329+329
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
Capacity Control % 4~100 4~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 7.2+9.5+11.7 7.2+11.5+11.5
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
