Planet XRT-501 [4/16] Configuration

l The Power LED should be ON.

l StatusLEDshouldash, andthenturnoff.Ifit stayson, thereisahardware

error.

l For each LAN connection, one of the LAN LEDs (10, 100, or 1000) should be

ON (provided the PC is also ON.)

l One of the WAN LEDs (10, 100, or 1000) should be ON, provided the Broad-

band modem is powered up.

2.2 Conguration

Then, you need to setup your LAN PC clients, so that it can obtain an IP address

automatically.By default theXRT-501’s DHCP serverisenabled, soyoucan obtain

an IP address automatically.

Note

PleasemakesurethattheXRT-501’sDHCPserveristheonlyDHCP

server available on your LAN. If there is another DHCP on your

network,thenyou’llneedtoswitchoneoftheDHCPserversoff.

Once your PC has obtained an IP address from your router, please start your Web

Browser. In the Address box, enter

http://192.168.0.1, and then press <enter>

The login screen below will appear. Enter the “User Name” and “Password” and

thenclick<OK>tologin.

Note

By default, the user name and password both are “admin”. For

security reasons it isrecommended to changethepasswordat the

firstloginandmemorizeit.
