1. Loosen the four screws

that secure the top panel.

13. Place the bracket with Raptor X

installed back to the front panel

and secures it with four screws

pictured.

14. Place the fans in the fan bracket

and fasten with screws.

15. Place the fan bracket with fans

installed back in the chassis and

secure with screws as pictured.

19. Then lift the bracket to detach. 20. Take out the optical drive and

the combo drive bracket that

you are going to install.

21. Place the optical drive in the

bracket and secure it with screws

as pictured.

2. Loosen the four screws that hold

the support brace, and then

remove the support brace.

3. Insert the motherboard standoffs

onto the chassis.

7. Install hard disk in the bracket

and secure it with screws, there

is room for five hard disk drives.

8. Loosen the six screws that hold

the cooling fan bracket to the

chassis.

9. Remove the cooling fan bracket.

For CW01-WD
