16. Place the hard disk drive bracket

with hard disk installed back on

top of cooling fan bracket and

secures it with screws.

10. Loosen the four screws that

secure the Raptor X bracket

11. Take out the Raptor X bracket. 12. Place the Raptor X in the bracket

and fasten the screws securely.

17. Loosen the screws that hold the

combo drive bracket in place.

18. First pull the combo drive

bracket towards the back

panel as pictured.

22. Place the bracket with optical

drive installed back in the

chassis, secure the bracket with

screws as pictured.

23. Install the power supply. 24. Re-install support brace and

then put the top panel back on

the case and secure it with 4

screws as pictured.

4. Place the motherboard over

standoffs and make sure

standoffs are securely tightened.

5. Loosen the four screws that hold

the hard disk drive bracket.

6. Take out the hard disk drive

bracket.

For CW01-WD

For CW01-WD For CW01-WD

CW01 / CW01-WD installation complete
