Streacom DA2 Performance Acrylic Panel Kit [2/4] Page 2

NET

Fan Mount

Outer Panel

Inner Panel

Overview

The performance acrylic panel kit is designed to replace the existing panels with ones that

feature larger openings for increased air flow and the ability to fit fans directly to the panels

using the included silicon fans mounts. The fan mounts allow for both 120 and 140mm fans

to be used and as they fit below the frame, save 15mm of space compared to using the

horizontal brackets.

The performance panels can be used in situations where additional cooling is required for

high power components or in conjunction with the tempered glass side panels in order to

compensate for the reduced ventilation.

Removing the pre-installed panels

Before installing the new acrylic panels, the original ones will need to be removed. We

recommend doing this without any components installed in the case for ease. The diagram

below shows the upper panels but the same applies to the lower side panels.

1. Carefully bend the outer panel until

the 4 notch cutouts clear the side of the

frame, then lift it out

2. Remove the PVC NET.

3. Bend the inner panel until the edge

clear the side of the frame, then lift it

out. The inner panel is thicker than the

upper one and will require more force.
