Planet DKVM-1700 [11/12] Replace bracket b and c step for cabinet depth is 504 614 mm

4.Adjust rail and input bracket A to rear of the rail then adjust bracket A to t

yourcabinet.Install2~3screws(don’ttight-up)uponthelengthyouneed.One

is forbidden.

bracket A

5. Repeat step 1 ~ 4 for the other side.

6.Repeatstep3~10ofinstallconsoletonishinstallation.

Replace bracket B and C step (For cabinet depth is 504 ~ 614 mm):

1.Removesevenrearscrews.

2.Taketwooriginalbracketsout.

original bracket
