Indoor Unit Lineup
1817
Ceiling Mounted Cassette (Double Flow) Type
Thin, lightweight, and easy to install in
narrow ceiling spaces
FXCQ20M/FXCQ25M/FXCQ32M
FXCQ40M/FXCQ50M/FXCQ63M
FXCQ80M/FXCQ125M
FXCQ-M 20
32/27
25/32
34/28
63
37/32
40/50
34/29
80
39/34
125
44/38
34/29 36/30 39/3437/32 41/36 46/40
(dB(A))
305 mm
The thin unit (only 305 mm high) can be
installed in a ceiling space as narrow as
350 mm. All models feature a compact
design with a depth of only 600 mm.
(When a high-efficiency filter is attached, the
unit's height is 400 mm.)
Low operation sound level
Designed with higher airflow suitable for
high ceiling application up to 3 metres.
Providing 2 different settings of standard
and ceiling soiling prevention, the auto
swing mechanism realises even distribution
of airflow and room temperature.
Two types of optional high-efficiency filter
are available (65% and 95%, colourimetric
method).
A long-life filter (maintenance free up to one
year
*)
is equipped as standard accessory.
Drain pump is equipped as standard
accessory with 600 mm lift.
Major maintenance work can be performed by
removing the panel. A flat-type suction grille
and a detachable blade make cleaning easy.
220 V
240 V
Sound level
(H/L)
600 mm
600 mm
Ceiling Mounted Cassette Corner Type
Slim design for flexible installation
Main body
Air discharge grille
(Option)
Set for front discharge using a suspended ceiling.
Downward discharge is shut off and air is blown straight out
(front discharge).
Front discharge is possible with an air
discharge unit (option), which allows the
installation in the drop-ceiling or sagging wall.
Single-flow type allows effective air discharge
from corner or from drop-ceiling.
Providing 3 different settings of standard, draft
prevention and ceiling soiling prevention, the
auto swing mechanism realises even
distribution of airflow and room temperature.
Main body
Downward discharge
Air discharge grille (Option)
FXKQ25MA/FXKQ32MA
FXKQ40MA/FXKQ63MA
3
32˚C
30˚C
28˚C 26˚C
24˚C
22˚C
20˚C
2
1
0
123456 (m)
(m)
500 mm
Drain pump is equipped as standard
accessory with 500 mm lift.
Panel spacer
20 mm
Min.195 mm
Slim body needs only 220 mm space above the
ceiling. If you use a panel spacer (option), the
unit can be installed in the minimum space of
195 mm.
* 8 hr/day, 25 day/month. For dust concentration of 0.15 mg/m
3
A long-life filter (maintenance free up to one
year
*)
is equipped as standard accessory.
* 8 hr/day, 25 day/month. For dust concentration of 0.15 mg/m
3
