Planet ENW-9503A [2/7] Hardware installation

Hardware Description

The ENW-9504 10/100 Fast Ethernet PCI Adapter has a RJ-45 connector and one

LED indicator.

LED Indicator

The adapter provides LED indicator for monitoring network conditions.

This section describes the function of LED.

LED Color Status Description

Off This card is not connect to the network.

On This card is connect to the network.

LNK/ACT Green

Blink

Indicate data is transferring and receiving via the

port.

Off This card is work with half-duplex.

Duplex Green

On This card is work with full-duplex.

This LED lights up to indicate the presence of network connection

Hardware Installation

1. Power off the PCI Local bus PC and remove its cover.

Please refer to your computer's Installation Manual for instructions on how to

remove the cover.

2. Select an available slot and plug in the adapter.

The adapter provides a 32-bit bus interface. It plugs into any available PCI bus slot

that supports Bus Master mode. Remove the bracket on the slot you've selected,

then insert the adapter into the slot. Carefully push the adapter into the slot until all

the edge connectors are firmly in place. Screw the adapter's face plate onto the

opening in the back of the computer to secure the connection. Then replace the PC's

cover.
