Daikin RXYHQ26P9W1B [5/12] What to do before operation

Daikin RXYHQ18P9W1B [5/12] What to do before operation
RXHQ + RXY(R)Q + RXYHQ + REMQ + REMHQ + REYQ + RXYSQ
VRVIII and VRVIII-S system air conditioner
4PW67777-1 – 01.2011
Operation manual
3
3. W
HAT
TO
DO
BEFORE
OPERATION
This operation manual is for the following systems with standard
control. Before initiating operation, contact your dealer for the
operation that corresponds to your system type and mark.
If your installation has a customized control system, ask your dealer
for the operation that corresponds to your system.
For the RXYRQ outdoor series, if the indoor unit is SA or RA, then
refer to the operation manual included with the indoor unit for more
information.
Outdoor units (See figure 1)
Names and functions of parts (See figure 1)
(figure 1 shows systems with changeover remote control switches.)
4. R
EMOTE
CONTROLLER
Refer to the operation manual of the remote controller.
5. C
HANGEOVER
SWITCH
: N
AME
AND
FUNCTION
OF
EACH
SWITCH
(See figure 2)
1
FAN ONLY/AIR CONDITIONING SELECTOR SWITCH
Set the switch to for fan only operation or to for heating or
cooling operation.
2
COOL/HEAT CHANGEOVER SWITCH
Set the switch to for cooling or to for heating operation.
6. O
PERATION
RANGE
Operation range
Use the system in the following temperature and humidity ranges for
safe and effective operation.
7. O
PERATION
PROCEDURE
■
Operation procedure varies according to the combination of
outdoor unit and remote controller. Read "3. What to do before
operation" on page 3.
■
To protect the unit, turn on the main power switch 6 hours before
operation.
■
If the main power supply is turned off during operation, operation
will restart automatically after the power turns back on again.
7.1. Cooling, heating, fan only, and automatic
operation
(See figure 3 and figure 4.1)
■
Changeover cannot be made with a remote controller whose
display shows (change-over under centralized control).
■
When the display (change-over under centralized control)
flashes, refer to "7.4. Setting the master remote controller" on
page 5.
■
Automatic operation can be selected only for REM(H)Q + REYQ
series.
■
RXHQ series let you select fan only and heating operation.
■
The fan may keep on running for about 1 minute after the
heating operation stops.
■
The air flow rate may adjust itself depending on the room
temperature or the fan may stop immediately. This is not a
malfunction.
Cool/heat
changeover
remote control
switch
Operation modes
Heating only
RXHQ
series
Heat pumps
RXY(H)Q series ❏ yes ❏ no
Heat pumps RXYRQ series ❏ yes ❏ no
Heat pumps RXYSQ series ❏ yes ❏ no
Heat recovery series
Heat pumps REM(H)Q series ❏ yes ❏ no
Heat pumps REYQ series ❏ yes ❏ no
1 Outdoor unit
2 Indoor unit
3 Remote controller
4 Inlet air
5 Outlet air
6 Cool/heat changeover remote control switch
7 BS (branch selector) unit
RXYRQ8~18P
RXYQ5~18P
RXYHQ12
REMQ8~16P
REMHQ12
REYQ8~16P
RXYRQ8~18P
RXHQ8~18P
RXYQ5~18P
RXYHQ12
REMQ8~16P
REMHQ12
REYQ8~16P
RXYSQ4~6P
Outdoor
temperature
–5~43°C DB –20~21°C DB –5~46°C DB
–20~24°C DB
(*)
(*) Range for operation: –20~–15°C WB. Range for continuous operation:
–15~15.5°C WB.
–20~15.5°C WB –20~15.5°C WB
Indoor
temperature
21~32°C DB 15~27°C DB 21~32°C DB 15~27°C DB
14~25°C WB 14~25°C WB
Indoor
humidity
≤80%
(†)
(†) to avoid condensation and water dripping out the unit.
If the temperature or the humidity is beyond these conditions, safety devices may
work and the air conditioner may not operate.
≤80%
(†)
