![Daikin RXYHQ26P9W1B [6/12] Program dry operation](/views2/1717734/page6/bg6.png)
Operation manual
4
RXHQ + RXY(R)Q + RXYHQ + REMQ + REMHQ + REYQ + RXYSQ
VRVIII and VRVIII-S system air conditioner
4PW67777-1 – 01.2011
For systems without cool/heat changeover remote control
switch (See figure 3)
1 Press the operation mode selector button several times and
select the operation mode of your choice.
2 Press the on/off button.
The operation lamp lights up and the system starts operation.
For systems with cool/heat changeover remote control switch
1 Select operation mode with the cool/heat changeover remote
control switch as follows:
2 Press the on/off button.
The operation lamp lights up and the system starts operation.
Adjustment
For programming temperature, fan speed and air flow direction, refer
to the operation manual of the remote controller.
Stopping the system
3 Press the on/off button once again.
The operation lamp goes off and the system stops operation.
Explanation of heating operation
It may take longer to reach the set temperature for general heating
operation than for cooling operation.
The following operation is performed in order to prevent the heating
capacity from dropping or cold air from blowing.
Defrost operation (heat pump and heat recovery types only)
■ In heating operation, freezing of the outdoor unit coil increases.
Heating capability decreases and the system goes into defrost
operation.
■ The indoor unit fan stops and the remote controller displays
.
■ After maximum 10 minutes of defrost operation, the system
returns to heating operation again.
Hot start (heat pump and heat recovery types only)
■ In order to prevent cold air from blowing out of an indoor unit at
the start of heating operation, the indoor fan is automatically
stopped. The display of the remote controller shows .
It may take some time before the fan starts. This is not a
malfunction.
7.2. Program dry operation
■ The function of this program is to decrease the humidity in your
room with minimal temperature decrease (minimal room
cooling).
■ The micro computer automatically determines temperature and
fan speed (cannot be set by the remote controller).
■ The system does not go into operation if the room temperature
is low (<20°C).
For systems without cool/heat changeover remote control
switch (See figure 5)
1 Press the operation mode selector button several times and
select (program dry operation).
2 Press the on/off button.
The operation lamp lights up and the system starts operation.
3 Press the air flow direction adjust button. (Only for Double-flow,
Multi-flow, Corner, Ceiling-suspended and Wall-mounted.) Refer
to "7.3. Adjusting the air flow direction" on page 5 for details.
Stopping the system
4 Press the on/off button once again.
The operation lamp goes off and the system stops operation.
Cooling operation
Heating operation
Automatic operation
Fan only operation
NOTE
Automatic operation (for REM(H)Q + REYQ series
only)
In the automatic operation mode, cool/heat changeover
is automatically conducted.
Cooling operation (figure 4.1)
Heating operation (figure 4.2)
Fan only operation (figure 4.3)
NOTE
Do not turn off power immediately after the unit stops,
but wait for at least 5 minutes.
NOTE
■ The heating capacity drops when the outside
temperature falls. If this happens, use another
heating device together with the unit. (When using
together with appliances that produce open fire,
ventilate the room constantly.)
Do not place appliances that produce open fire in
places exposed to the air flow from the unit or
under the unit.
■ It takes some time to heat up the room from the
time the unit is started since the unit uses a hot-air
circulating system to heat the entire room.
■ If the hot air rises to the ceiling, leaving the area
above the floor cold, we recommend that you use
the circulator (the indoor fan for circulating air).
Contact your dealer for details.
NOTE
Do not turn off power immediately after the unit stops,
but wait for at least 5 minutes.
