11
Model ISW-621 ISW-621S15
Hardware Specication
Copper
Ports 4 x 10/100Base-TX, Auto-negotiation, Auto-MDI/MDI-X
Cable
10Base-T: 2-pair UTP Cat. 3, 4, 5 cable (100meters, max.)
100Base-TX: 2-pair UTP Cat. 5 cable (100meters, max.)
Fiber
Optical
Port 2 x 100Base-FX
Cable 50/125μm or 62.5/125μm ber 9/125μm ber
Mode Multi-mode Single-mode
Distance 2km 15km
Dimensions
(W x D x H)
135mm x 97mm x 32mm
Weight 442g
Power Requirement
12~48 VDC,
Redundant power with polarity reverse protection function
Power Consumption
/ Dissipation
11.6 Watts / 40BTU
Installation DIN rail kit and wall mount ear
Switch Specication
Switch Processing
Scheme
Store-and-Forward
Address Table 2K entries
Buffer 1Mbit
Flow Control
Back pressure for half duplex,
IEEE 802.3x Pause Frame for full duplex
Switch Fabric 1.2Gbps
Throughput
(Packet Per Second)
0.89Mpps @ 64Bytes
Standards Conformance
Standards
Compliance
IEEE 802.3 Ethernet, 10Base-T
IEEE 802.3u Fast Ethernet, 100Base-TX, 100Base-FX
IEEE 802.3x Full-duplex ow control
Temperature
Operating: -10~60 Degree C
Storage: -40~85 Degree C
Humidity Operating Operating: 5% to 90%, Storage: 5% to 90% (Non-condensing)
Regulation
Compliance
FCC Part 15 Class A, CE
