SiUS34-801A_b List of Electrical and Functional Parts
Appendix 511
3.1.2 REYQ72PYDN~120PYDN
Item Name Symbol
Model
REYQ72PYDN REYQ96PYDN REYQ120PYDN
Compressor
Inverter
Type
M1C
JT1GCVDKYR@SA
OC protection
device
14.7A
STD 1
Type
M2C
JT170G-KYE@T
OC protection
device
15.0A
Fan motor
OC protection
device
M1F 3.0A
3.0A
(for General
overseas : 1.14A)
Electronic expansion valve (Main) Y1E Fully closed: 0pls Fully open: 1375pls
Electronic expansion valve (Subcool) Y2E Fully closed: 0pls Fully open: 480pls
Electronic expansion valve (Refrigerant charge) EV 0~480pls
Pressure
protection
High pressure
switch
For M1C S1PH OFF: 580 psi ON: 435±21.75psi
For M2C S2PH OFF: 580 psi ON: 435±21.75psi
Low pressure sensor SENPL OFF: 10.15psi
Temperature
protection
Discharge gas temperature
protection
(Discharge pipe thermistor)
R3T OFF: 275°F
Inverter fin temperature
protection
(Radiator fin thermistor)
R1T OFF: 199.4°F
Others Fuse
For main PC
board
F1U 250V AC 10A Class B Time-lag 3.15A AC 250V
F2U 250V AC 10A Class B Time-lag 3.15A AC 250V
For Noise filter
PC board
F1U 250V AC 5A Class B
+0
−17.40
+0
−17.40
