EDUS301214-N Installation Manual
Installation of Outside Units 11
3P153897-12X
2-5 Technical specifications
(1)
(1)
Refer to the engineering data book for the complete list of specifications.
(2)
The
normal cooling capacities are based on:
–
Indoor temperature: 80
°FDB / 67°FWB
–Entering
water temperature: 85
°F
–
Leaving water temperature: 95
°F
–Equivalent pipe length: 25 ft
–Level difference: 0 ft
(3)
The
normal heating capacities are based on:
–
Indoor temperature: 70
°FDB / 60°FWB
–
Entering water temperature: 70
°F
–Equivalent pipe length: 25 ft
–Level difference: 0 ft
(4)
The nominal input includes total input of the unit: compressor and control circuit.
(5) In case of heat recovery system
2-6 Electrical specifications
General
RWEYQ72PYDN/TJU RWEYQ84PYDN/TJU
Nominal cooling capacity (2)
(MBH)
72 84
Nominal heating capacity (3) (MBH)
81 94.5
Nominal input cooling / heating (4)
(kW) 4.20 / 4.00 5.60 / 5.40
Dimensions HxWxD (inch) 39-3/8×30-3/4×21-11/16
Weight (YDN/TJU) (lbs) 343/330 343/330
Connections
refrigerant liquid pipe (inch) 3/8 3/8
refrigerant gas pipe (inch) 3/4 7/8
refrigerant discharge gas pipe (5)
(inch) 5/8 3/4
Water piping connections
Inlet pipe (inch)
1-1/4FPT
female Thread
1-1/4FPT
female Thread
Outlet pipe (inch)
1-1/4FPT
female Thread
1-1/4FPT
female Thread
Drain pipe (inch)
1/2FPS
female Thread
1/2FPS
female Thread
General
RWEYQ144PYDN/TJU RWEYQ168PYDN/TJU
Nominal cooling capacity (2)
(MBH)
144 168
Nominal heating capacity (3) (MBH)
162 189
Nominal input cooling / heating (4)
(kW) 8.40 / 8.00 11.20 / 10.80
Dimensions HxWxD (inch) (39-3/8×30-3/4×21-11/16)×2
Weight (YDN/TJU) (lbs) 343×2/330×2 343×2/330×2
Connections
refrigerant liquid pipe (inch) 1/2 5/8
refrigerant gas pipe (inch) 1-1/8 1-1/8
refrigerant discharge gas pipe (5)
(inch) 7/8 7/8
Water piping connections
Inlet pipe (inch)
(1-1/4FPT)×2
female Thread
(1-1/4FPT)×2
female Thread
Outlet pipe (inch)
(1-1/4FPT)×2
female Thread
(1-1/4FPT)×2
female Thread
Drain pipe (inch)
(1/2FPS)×2
female Thread
(1/2FPS)×2
female Thread
General
RWEYQ216PYDN/TJU RWEYQ252PYDN/TJU
Nominal cooling capacity (2)
(MBH)
216 252
Nominal heating capacity (3)
(MBH)
243 283.5
Nominal input cooling / heating (4)
(kW) 12.60 / 12.00 16.80 / 16.20
Dimensions HxWxD (inch) (39-3/8×30-3/4×21-11/16)×3
Weight (YDN/TJU) (lbs) 343×3/330×3 343×3/330×3
Connections
refrigerant liquid pipe (inch) 5/8 3/4
refrigerant gas pipe (inch) 1-1/8 1-1/4
refrigerant discharge gas pipe (5)
(inch) 1 1-1/8
Water piping connections
Inlet pipe (inch)
(1-1/4FPT)×3
female Thread
(1-1/4FPT)×3
female Thread
Outlet pipe (inch)
(1-1/4FPT)×3
female Thread
(1-1/4FPT)×3
female Thread
Drain pipe (inch)
(1/2FPS)×3
female Thread
(1/2FPS)×3
female Thread
Compressor
RWEYQ72PYDN/TJU RWEYQ84PYDN/TJU
Oil type
Synthetic (ether) oil Synthetic (ether) oil
Crankcase heater (W) 33 33
Refrigerant type R410A R410A
Refrigerant charge (lbs) 9.9 11.5
Compressor
RWEYQ144PYDN/TJU RWEYQ168PYDN/TJU
Oil type
Synthetic (ether) oil Synthetic (ether) oil
Crankcase heater (W) (33)×2 (33)×2
Refrigerant type R410A R410A
Refrigerant charge (lbs) (9.9)×2 (11.5)×2
Compressor
RWEYQ216PYDN/TJU RWEYQ252PYDN/TJU
Oil type
Synthetic (ether) oil Synthetic (ether) oil
Crankcase heater (W) (33)×3 (33)×3
Refrigerant type R410A R410A
Refrigerant charge (lbs) (9.9)×3 (11.5)×3
Model
RWEYQ72PYDN RWEYQ84PYDN
Power supply
Phase 3~ 3~
Frequency (Hz) 60 60
Voltage (V) 460 460
Voltage tolerance (%) ±10 ±10
Recommended fuses (A) 15 15
Compressor
Phase 3~ 3~
Frequency (Hz) 60 60
Voltage (V) 460 460
Nominal running current (A) 5.3 7.0
Model
RWEYQ144PYDN RWEYQ168PYDN
Power supply
Phase 3~ 3~
Frequency (Hz) 60 60
Voltage (V) 460 460
Voltage tolerance (%) ±10 ±10
Recommended fuses (A) (15)×2 (15)×2
Compressor
Phase 3~ 3~
Frequency (Hz) 60 60
Voltage (V) 460 460
Nominal running current (A) (5.3)×2 (7.0)×2
Model
RWEYQ216PYDN RWEYQ252PYDN
Power supply
Phase 3~ 3~
Frequency (Hz) 60 60
Voltage (V) 460 460
Voltage tolerance (%) ±10 ±10
Recommended fuses (A) (15)×3 (15)×3
Compressor
Phase 3~ 3~
Frequency (Hz) 60 60
Voltage (V) 460 460
Nominal running current (A) (5.3)×3 (7.0)×3
