+5V +12V +3.3V -12V +5Vsb
0.5A 1.0A 0.3A 0.0A 0.0A
6.0A 2.0A 6.0A 0.0A 0.1A
13.0A 9.0A 12.0A 0.1A 0.5A
17.0A 20.0A 10.5 A 0.2A 1.0A
11.0A 26.0A 20.0A 0.2A 1.5A
6.5A 46.0A 10.0A 0.3A 2.5A
8.5A 50.0A 0.3A 0.3A 0.5A
0.5A 2.0A 0.3A 0.0A 0.0A
LOAD1
LOAD2
LOAD3
LOAD4
LOAD5
LOAD6
LOAD7
LOAD8
＊ The continuous total output power is 750W max.
• The combined power of +5V and +3.3V is 120W max.
• Peak currents may last up to 12 seconds with not more than one occurrence per minute.
＊ Add 0.1uF and 10uF capacitors across output terminal during ripple & noise test.
＊ LOAD REGULATION TEST TABLE:
ET750-B
Voltage
+5V +3.3V +12V -12V +5Vsb
＊
Max load
22.0A 22.0A 62.0A 0.3A 2.5A
Min load
0.0A 0.0A 0.0A 0.0A 0.0A
Peak load
-- -- -- -- 3.0A
＊
Combined power
120W -- -- --
＊
Regulation
+5,-5% +5,-5% +5,-5% +10,-10% +5,-5%
＊
Ripple & Noise
50mV 50mV 120mV 120mV 50mV
06
