SilverStone SST-ET450-B [9/16] Manual et450 b et550 b et650 b et750 b p7 v1
![SilverStone SST-ET450-B [9/16] Manual et450 b et550 b et650 b et750 b p7 v1](/views2/1718819/page9/bg9.png)
+5V +12V +3.3V -12V +5Vsb
0.0A 0.0A 0.0A 0.0A 0.0A
5.0A 0.5A 5.0A 0.0A 0.1A
10.0A 5.0A 10.0A 0.1A 0.5A
22.0A 10.0A 3.0A 0.2A 1.0A
9.0A 15.0A 22.0A 0.2A 2.5A
0.0A 65.0A 0.0A 0.3A 0.5A
12.0A 53.0A 12.0A 0.3A 2.0A
0.3A 0.3A 0.3A 0.0A 0.0A
LOAD1
LOAD2
LOAD3
LOAD4
LOAD5
LOAD6
LOAD7
LOAD8
Output voltage
Max. step size
+5V
30%
+3.3V
30%
+12V
30%
TTL High/PS-OFF; TTL Low/PS-ON
VIL=0.8Vmax, IIL=-1.6mAmax @Vin=0.4V
VIH=2.0Vmin @Iin=-200uA, VIH=5.25Vmax @open ckt.
2.1 REMOTE ON/OFF
10msec (minimum) at 80% of full load at 230Vac input.
2.2 HOLD-UP TIME
100-500 msec.
2000 msec max.At nominal line full load.
2.3 POWER GOOD DELAY
2.5 TURN-ON DELAY TIME
DC output transient step sizes as below table:
2.6 TRANSIENT OVERSHOOT
2.4 POWER FAIL DELAY
1 msec.
Load-changing repetition rate of 10m seconds.
+5V
10000uF
+3.3V
10000uF
+12V
10000uF
-12V
470uF
+5Vsb
3300uF
Load slew rated 1.0A/uS and capacitive load as below :
07
