SiE00-01 Product Specification
Product Specification 7
Test conditions are as follows
Notes:
1. Operation sound is measured at 1.5 m below the center the body.
2. Fan speed can be changed over to Low mode or High mode.
3. Operating sound is measured in an anechoic chamber.
Operating sound level generally become greater than this value depending on the operating conditions,
reflected sound, and peripheral noise.
4. The sound level at the air discharge port is about 8 dB higher than the unit’s operating sound.
(50 / 60Hz)
Model Name VAM500FJVE VAM650FJVE VAM800FJVE
Power Supply Single Phase 220 – 240 V / 220 V, 50 / 60 Hz
Temperature Exchanging
Efficiency
Ultra-High % 74 / 74 74 / 74 74 / 74
High % 74 / 74 74 / 74 74 / 74
Low % 77 / 78.5 77 / 78 76 / 76
Enthalpy
Exchange
Efficiency
Cooling Ultra-High % 58 / 58 58 / 58 60 / 60
High % 58 / 58 58 / 58 60 / 60
Low % 63 / 65.5 63 / 65 62 / 63
Heating Ultra-High % 62 / 62 63 / 63 65 / 65
High % 62 / 62 63 / 63 65 / 65
Low % 67 / 68.5 66 / 68 67 / 68
Casing Galvanized Steel Plate
Insulating Material Self-extinguishable Urethane Foam
Dimensions H x W x D mm 285 x 812 x 800 348 x 988 x 852 348 x 988 x 852
Heat Exchanging System Air to Air Cross Flow Total Heat (Sensible Heat + Latent Heat) Exchange
Heat Exchanging Element Specially Processed Nonflammable Paper
Air Filter Multidirectional Fibrous Fleeces
Fan Type Sirroco Fan
Fan
Speed
Ultra-High m
³
/ h 500 / 500 650 / 650 800 / 800
High m
³
/ h 500 / 500 650 / 650 800 / 800
Low m
³
/ h 350 / 300 500 / 440 670 / 660
External
Static
Pressure
Ultra-High Pa 98 / 147 93 / 162 137 / 225
High Pa 54 / 54 39 / 69 98 / 118
Low Pa 25 / 20 25 / 34 49 / 69
Fan Motor Type Open Type Capacitor Permanent Split-phase Induction Motor, 4 Poles x 2
Motor Output kW 0.090
∞
2 0.140
∞
2 0.230
∞
2
Operating
Sound
Heat
Exchange
Mode
Ultra-High dBA 33 – 34.5 / 34 34.5 – 35.5 / 36 36 – 37 / 37
High dBA 31.5 – 33 / 31 33 – 34 / 33 34.5 – 36 / 35
Low dBA 24.5 – 26.5 / 24 27 – 28 / 27 31 – 32 / 30
Byapss
Mode
Ultra-High dBA 33.5 – 34.5 / 35 34.5 – 35.5 / 35.5 36 – 37 / 37
High dBA 32.5 – 33.5 / 33 34 – 35 / 34 34.5 – 36 / 35
Low dBA 25.5 – 27.5 / 24 27 – 28.5 / 27 31 – 33 / 31
Operation Range (Ambient) – 10
°
C to 50
°
CDB (80% RH or Less)
Connection Duct Diameter mm
φ
200
φ
200
φ
250
Weight kg 33 48 48
Drawing Number 4D020374A 4D020375A 4D020376A
Condition
Indoor Outdoor
°
CDB R.H (%)
°
CDB R.H (%)
Cooling condition 27 50 35 60
Heating condition 20 40 7 70
