<Table 2>
Groups Type of room
Ventilation
required
Groups Type of room
Ventilation
required
Common
household
Living room 6
Playhouses
and movie
theaters
Audience room 6
Bathroom 6 Corridor 6
Drawing room 6 Smoking room 12
Toilet10Toilet12
Kitchen 15 Projector room 20
Dining
places
Restaurant 6
Plants
Office room 6
Sushi restaurant 6 General work room 6
Banquet hall 10 Telephone room 6
Tempura restaurant 20 Spinning plant, 10
Cooking room 20 Printing plant 10
Inns and
hotels
Guest room 5 Battery room 10
Corridor 5 Machinery plant 10
Dance hall 8 Generator room 15
Large dining hall 8 Substation room, 15
Washroom, Toilet 10 Painting shop, 15
Cooking room 15 Welding plant 15
Laundry room 15 Chemical plant 15
Engine room 20 Food plant 20
Boiler room 20 Wood working plant 20
Hospitals
Consultation office 6
Casting plant 50
General
buildings
Office room 6
Waiting room 10
Show room, Toilet 10
Conference room 12
Comfort
stations
20
Dark rooms Dark rooms for photo 16
Sick room 6
Guest
rooms of
ship
6
Office room 6
Room of potential noxious gas or
combustible gas
20 or
more
Corridor 10
Waiting room 10
Bathroom 10
Dining room, Toilet 10
Respiratory disease room 10
Laundry room 15
Cooking room 15
Surgery room 15
Sterilizing room 15
Engine room 20
Boiler room 20
Schools
Class room, library 6
Auditorium 6
Experimental chemistry
room
6
Gymnasium 8
Toilet 12
Cooking room 15
