SilverStone ST65F-GS [8/12] Power supply connector overuse definition

6.1 Underwriters Laboratory (UL) recognition.

The power supply designed to meet UL 60950.

The demonstrated MTBF shall be 100,000 hours of continuous operation at 25oC, full load and

120V AC input. The MTBF of the power supply shall be calculated in accordance with

MIL-HDBK-217F. The DC FAN is not included.

7.1 ELECTROSTATIC DISCHARGE (ESD) – IEC 61000-4-2(EN 61000-4-2).

7.2 RADIATED SUSCEPTIBILTY – IEC 61000-4-3(EN 61000-4-3).

7.4 SURGE – IEC 61000-4-5(EN 61000-4-5).

7.5 CONDUCTED SUSCEPTIBILTY – IEC 61000-4-6(EN 61000-4-6).

7.6 POWER FREQUENCY MAGNETIC FIELD – IEC 61000-4-8(EN 61000-4-8).

7.7 VOLTAGE DIPS – IEC 61000-4-11(EN 61000-4-11).

7.8 VOLTAGE FLUCTUATIONS – IEC 61000-3-3 (EN 61000-3-3).

7.9 HARMONIC CURRENT EMISSION – IEC61000-3-2(EN 61000-3-2).

7.10 EN55032:Class B Radio interference (CISPR 22).

8.1 MTBF (mean time between failures) calculation

7.11 ANSI C63.4-2009 / FCC Part 15 Subpart B / ICES-003 lssue 5 Class B

115VAC operation.

7.3 ELECTRICAL FAST TRANSIENT / BURST ( EFT/B) – IEC 61000-4

-4(EN 61000-4-4).

9.1 Physical dimension : W150mm*H86mm*D140mm

6.0 SAFETY

7.0 ELECTROMAGNETIC COMPATIBILITY (EMC)

8.0 MTBF

9.0 MECHANICAL REQUIREMENTS

10.0 Power supply connector overuse definition
