3.2 Remote On/Off Controlled mode
3.3 Regulation
ST75F-GS
The cross regulation defined as follows, the output regulation should be within the specified range.
3.4 Rise Time
DC output rise time is less than 20 mS at nominal line and full load.
The PSON# signal is required to remotely turn on/off the power supply, PSON# is an active low signal
that turns on the output power rails. When this is not pulled low by the system, or left open, the outputs
(except the +5VSB) turn off. This signal is pulled to a standby voltage by a pull-up resistor internal to
the power supply.
TTL level "H" 2.0 V - 5.25 V
"L" 0.0 V – 1.0 V
Load
Light Load.
Typical Load
Full Load
+5V
2.44A
6.10A
12.20A
+3.3V
2.44A
6.10A
12.20A
+12V
10.55A
26.38A
52.75A
-12V
0.05A
0.13A
0.25A
+5Vsb
0.51A
1.27A
2.53A
ST65F-G
Load
Light Load.
Typical Load
Full Load
+5V
2.38A
5.96A
11.92A
+3.3V
2.38A
5.96A
11.92A
+12V
8.93A
22.32A
44.65A
-12V
0.05A
0.12A
0.25A
+5Vsb
0.49A
1.24A
2.47A
ST55F-G
Load
Light Load.
Typical Load
Full Load
+5V
2.07A
5.16A
10.33A
+3.3V
2.07A
5.16A
10.33A
+12V
7.48A
18.71A
37.42A
-12V
0.05A
0.12A
0.24A
+5Vsb
0.49A
1.22A
2.45A
