SilverStone ST40NF [5/12] Dc output

2.1 DC voltage regulation

2. DC OUTPUT

2.2 Load Ranges

2.2.1 Typical Power Distribution for 500W ATX12V Configuration

2.2.2 Typical Power Distribution for a 400W ATX12V Configuration

Note:

( 1 )Total combined output load of +3.3V and +5V is ≦110W.

( 2 )+12V Maximum output power should not exceed 456W.

( 3 )When +5V load is over 15A,+12V min load is 2A.

( 4 )When +12V load is over 30A,+5V min load is 4A.

( 5 )Maximum continuous total DC output power should not exceed 500W.

( 6 )Peak DC output power should not exceed 520W for 12 second.

Parameter Range Min Nom Max Unit

+3.3V +/-5% +3.14 +3.3 +3.47 Volts

+5V +/-5% +4.75 +5.0 +5.25 Volts

+12V +/-5% +11.40 +12.0 +12.6 Volts

-12V +/-10% -10.80 -12.0 -13.2 Volts

+5VSB +/-5% +4.75 +5.0 +5.25 Volts

Parameter Min Nom Max Peak Unit

+3.3V 0.1 - 18 - Amps

+5V 0.2 - 16 - Amps

+12V 0.5 - 38 - Amps

-12V 0.0 - 0.3 - Amps

+5VSB 0.0 - 2.5 - Amps

Parameter Min Nom Max Peak Unit

+3.3V 0.1 - 16 - Amps

+5V 0.2 - 16 - Amps

+12V 0.5 - 38 - Amps

-12V 0.0 - 0.3 - Amps

+5VSB 0.0 - 2.5 - Amps
