SilverStone ST40NF [7/12] Protection

04

2.4 Overshoot

Any overshoot at turn on or turn off shall be less 10% of the nominal voltage value, all outputs shall

be within the regulation limit of section 2.0 before issuing the power good signal of section 5.0.

2.5 Efficiency

Power supply typical efficiency is 82% under full Load at nominal input voltage of 115VAC or

230VAC.

2.6 Remote on/off control

When the logic level "PS-ON" is low, the DC outputs are to be enabled.

500W 400W

The over voltage sense circuitry and reference shall reside in packages that are separate and

distinct from the regulator control circuity and reference. No single point fault shall be able to cause

a sustained over voltage condition on any or all outputs. The supply shall provide latch-mode over

voltage protection as defined in Table.

No damage or hazardous condition should occur with all the DC output connectors disconnected

from the load. The power supply may latch into the shutdown state.

Output Minimum Nominal Maximum Unit

+12 VDC 13.4 15.0 17 Volts

+5 VDC 5.74 6.3 7.5 Volts

3. PROTECTION

24 40 A24 40 A
