Functions SiBE041134EB
2 List of Functions
1. Functions
Category Functions
FTXS20/25K2V1B
RXS20/25K2V1B, RXS20/25K3V1B
RXS20/25L2V1B
Category Functions
FTXS20/25K2V1B
RXS20/25K2V1B, RXS20/25K3V1B
RXS20/25L2V1B
Basic
Functions
Inverter (with inverter power control) z Health &
Cleanliness
Air-purifying filter —
Operation limit for cooling (°CDB)
–10
~ 46
Photocatalytic deodorizing filter —
Operation limit for heating (°CWB)
–
15
~ 18
Air-purifying filter with photocatalytic
deodorizing function
—
PAM control z
Titanium apatite photocatalytic
air-purifying filter
z
Standby electricity saving z
Compressor Oval scroll compressor — Air filter (prefilter) z
Swing compressor z Wipe-clean flat panel z
Rotary compressor — Washable grille —
Reluctance DC motor z MOLD PROOF operation —
Comfortable
Airflow
Power-airflow flap z Good-sleep cooling operation —
Power-airflow dual flaps — Timer WEEKLY TIMER operation z
Power-airflow diffuser — 24-hour ON/OFF TIMER z
Wide-angle louvers z NIGHT SET mode z
Auto-swing (up and down) z Worry Free
(Reliability &
Durability)
Auto-restart (after power failure) z
Auto-swing (right and left) — Self-diagnosis (R/C, LED) z
3-D airflow — Wiring error check function —
COMFORT AIRFLOW operation z
Anti-corrosion treatment of outdoor heat
exchanger
z
Comfort
Control
Auto fan speed z Flexibility Multi-split / split type compatible indoor unit z
Indoor unit quiet operation z H/P, C/O compatible indoor unit —
NIGHT QUIET mode (automatic) — Flexible power supply correspondence —
OUTDOOR UNIT QUIET operation (manual) z Chargeless 10 m
2-area INTELLIGENT EYE operation — Either side drain (right or left) z
INTELLIGENT EYE operation z Power selection —
Quick warming function (preheating control) z Remote
Control
5-room centralized controller (option) z
Remote control adaptor
(normal open pulse contact) (option)
zHot-start function z
Automatic defrosting z
Remote control adaptor
(normal open contact) (option)
z
Operation Automatic operation z
Program dry operation z DIII-NET compatible (adaptor) (option) z
Fan only z Remote
Controller
Wireless z
Lifestyle
Convenience
New POWERFUL operation
(non-inverter)
— Wired (option) z
Inverter POWERFUL operation z
Priority-room setting —
COOL/HEAT mode lock —
HOME LEAVE operation —
ECONO operation z
Indoor unit ON/OFF button z
Signal receiving sign z
R/C with back light z
Temperature display —
Note:
z
: Available
— : Not available
: Lower limit can be extended by cutting jumper.
(Facility use only)
Refer to page 110 for details.
