Specifications SiBE041134EB
10 Specifications
50 Hz, 220 - 230 - 240 V
Note:
The data are based on the conditions shown in the table below.
Model
Indoor Unit ATXS25K2V1B ATXS25K3V1B
Outdoor Unit
ARXS25L2V1B ARXS25L3V1B
Cooling Heating Cooling Heating
Capacity Rated
(Min. ~ Max.)
kW 2.5 (1.3 ~ 3.2) 2.8 (1.3 ~ 4.7) 2.5 2.8 (1.3 ~ 4.7)
Btu/h 8,500 (4,400 ~ 10,900) 9,600 (4,400 ~ 16,000) 8,500 (4,400 ~ 10,900) 9,600 (4,400 ~ 16,000)
kcal/h 2,150 (1,120 ~ 2,750) 2,410 (1,120 ~ 4,040) 2,150 (1,120 ~ 2,750) 2,410 (1,120 ~ 4,040)
Running Current (Rated) A 3.2 - 3.1 - 3.0 3.3 - 3.2 - 3.1 3.38 - 3.28 - 3.17 3.3 - 3.2 - 3.1
Power Consumption Rated
(Min. ~ Max.)
W 570 (320 ~ 1,000) 620 (310 ~ 1,410) 602 (320 ~ 1,000) 620 (310 ~ 1,410)
Power Factor % 81.0 - 79.9 - 79.2 85.4 - 84.2 - 83.3 81.0 - 79.9 - 79.2 85.4 - 84.2 - 83.3
COP (Rated) W/W 4.39 (4.06 ~ 3.20) 4.52 (4.19 ~ 3.33) 4.15 (4.06 ~ 3.20) 4.52 (4.19 ~ 3.33)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5
Drain mm φ 18.0 φ 18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. lnterunit Piping Length m 20 20
Max. lnterunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Unit ATXS25K2V1B ATXS25K3V1B
Front Panel Color White White
Airflow Rate
H
m³/min
(cfm)
9.1 (321) 10.0 (353) 9.1 (321) 10.0 (353)
M 7.0 (247) 8.0 (282) 7.0 (247) 8.0 (282)
L 5.0 (177) 6.0 (212) 5.0 (177) 6.0 (212)
SL 3.9 (138) 4.3 (152) 3.9 (138) 4.3 (152)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 16 16
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.19 - 0.18 - 0.17 0.19 - 0.18 - 0.17 0.19 - 0.18 - 0.17 0.19 - 0.18 - 0.17
Power Consumption (Rated) W 40 - 40 - 40 40 - 40 - 40 40 - 40 - 40 40 - 40 - 40
Power Factor % 95.7- 96.6 - 98.0 95.7- 96.6 - 98.0 95.7 - 96.6 - 98.0 95.7 - 96.6 - 98.0
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 289 × 780 × 215 289 × 780 × 215
Packaged Dimensions (H × W × D) mm 274 × 850 × 346 274 × 850 × 346
Weight (Mass) kg 8 8
Gross Weight (Gross Mass) kg 12 12
Sound Pressure Level (H / M / L / SL) dB(A) 41 / 33 / 25 / 19 41 / 34 / 27 / 19 41 / 33 / 25 / 19 41 / 34 / 27 / 19
Sound Power Level (H) dB 58 58 58 58
Outdoor Unit ARXS25L2V1B ARXS25L3V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23APXD 1YC23AWXD
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Type R-410A R-410A
Charge kg 1.0 1.0
Airflow Rate
H
m³/min
(cfm)
33.5 (1,183) 28.3 (999) 33.5 (1,183) 28.3 (999)
SL 30.1 (1,063) 25.6 (904) 30.1 (1,063) 25.6 (904)
Fan
Type Propeller Propeller
Motor Output W 23 50
Running Current (Rated) A 2.21 - 2.12 - 2.03 2.61 - 2.52 - 2.43 3.19 - 3.10 - 3.00 2.61 - 2.52 - 2.43
Power Consumption (Rated) W 530 - 530 - 530 580 - 580 - 580 562 - 562 - 562 580 - 580 - 580
Power Factor % 80.0 - 78.9 - 78.0 84.8 - 83.5 - 82.5 80.1 - 78.9 - 78.1 84.8 - 83.5 - 82.5
Starting Current A 3.3 3.3
Dimensions (H × W × D) mm 550 × 765 × 285 550 × 765 × 285
Packaged Dimensions (H × W × D) mm 612 × 906 × 364 612 × 906 × 364
Weight (Mass) kg 34 34
Gross Weight (Gross Mass) kg 38 37
Sound Pressure Level (H / L / SL) dB(A) 46 / - / 43 47 / 44 / - 46 / - / 43 47 / 44 / -
Sound Power Level (H) dB 59 59 59 59
Drawing No. 3D086540 3D092026A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
5 m
