SiBE041213E Field Settings
Tips for Servicing 110
3.5 Jumper Settings
Indoor Unit
For the location of the jumper, refer to page 7.
Outdoor Unit
For the location of the jumper, refer to page
9, 11, 12
.
Caution Replace the PCB if you accidentally cut a wrong jumper.
Jumpers are necessary for electronic circuit. Improper operation may occur if you cut any of
them.
Function Jumper Jumper: connected
(factory set)
Jumper: cut
Fan speed setting when
compressor stops for
thermostat OFF. (effective only
in cooling operation)
JB Fan speed setting ;
Remote controller
setting
Fan speed setting; “0” (The fan
stops.)
Power failure recovery function JC Auto-restart The unit does not resume
operation after recovering from a
power failure. Timer settings are
cleared.
Function Jumper Jumper: connected
(factory set)
Jumper: cut
Improvement of defrost
performance
35/42 class
→
J5
50 class
→
J8
Standard control Reinforced control (ex.
The frequency
increases, the duration
time of defrost
lengthens.)
