Piping Diagrams SiBE041213E
113 Appendix
1. Piping Diagrams
1.1 Indoor Unit
1.2 Outdoor Unit
RXS35K2V1B
FTXS35/42K2V1B FTXS50K2V1B
INDOOR UNIT
6.4CuT
HEAT EXCHANGER
CROSS FLOW FAN
M
FAN MOTOR
9.5CuT
REFRIGERANT FLOW
COOLING
HEATING
FIELD PIPING
6.4CuT
FIELD PIPING
9.5CuT
THERMISTOR
ON HEAT EXCH.
4D058897K
INDOOR UNIT
6.4CuT
HEAT EXCHANGER
CROSS FLOW FAN
M
FAN MOTOR
9.5CuT
REFRIGERANT FLOW
COOLING
HEATING
FIELD PIPING
6.4CuT
FIELD PIPING
12.7CuT
THERMISTOR
ON HEAT EXCH.
4D058898G
OUTDOOR UNIT
HEAT EXCHANGER
7.0CuT
7.0CuT
9.5CuT
EV
4.8CuT
6.4CuT
6.4CuT
4.8CuT
M
PROPELLER FAN
9.5CuT
9.5CuT
6.4CuT
7.9CuT
9.5CuT
MUFFLER
9.5CuT 9.5CuT
COMPRESSOR
MUFFLERMUFFLER
7.9CuT
ACCUMULATOR
REFRIGERANT FLOW
COOLING
HEATING
OUTDOOR TEMPERATURE
THERMISTOR
HEAT EXCHANGER
THERMISTOR
DISCHARGE PIPE
THERMISTOR
GAS STOP
VALVE
LIQUID STOP
VALVE
FIELD PIPING
(6.4CuT)
FIELD PIPING
(9.5CuT)
MUFFLER
WITH
FILTER
φ.4.0×ID. 2.0CuT
ELECTRONIC
EXPANSION
VALVE
MUFFLER
WITH
FILTER
MUFFLER
WITH
FILTER
FOUR WAY
VALVE
ON: HEATING
3D059586Q
