Daikin FLKS60BAVMB [7/15] Indoor unit installation drawings
![Daikin FLXS35BVMB [7/15] Indoor unit installation drawings](/views2/1720624/page7/bg7.png)
5 ■English
Indoor Unit Installation Drawings
1.
Ceiling mounting.
2.
Wall mounting.
Local drain pipe
Ceiling
Wall
*1 Determine the position of the
feed-through hole so that the
local piping is placed in a
downward sloping direction.
40
*1 more than 170
Ceiling
Rear side pipinghole ø65mm
Rear side drainhose hole ø40mm
55
50
35
40-45
22
40
Right side piping
hole ø65mm
Drain hose
1,050
980
230138
490
55
40
Wall
Top side piping hole ø65mm
35
Right side
piping hole
ø80mm
Wall
Floor
40
40
Wall
Under side piping
hole ø80mm
55
30
97 48
Drain pipe
Gas pipe
Liquid pipe
Connection position
102
26
150
Wall
Floor
55
40
1,050
800
162255
490
Floor
Rear side piping hole
ø80mm
01_EN_3P171284-2D.fm Page 5 Monday, August 23, 2010 2:33 PM
