SilverStone ST60F [10/12] St60f manual 10
![SilverStone ST60F [10/12] St60f manual 10](/views2/1720886/page10/bga.png)
09
6PIN PCI Express connector #1 & #2 & #3 & #4
18AWG wire Signal Pin Pin Signal 22AWG wire
+12V2 1 4 COM Black
+12V2 2 5 COM Black
+12V2 3 6 COM Black
Yellow/Blue stripe
Yellow/Blue stripe
Yellow/Blue stripe
8PIN PCI Express connector
+12V2 1 5 COM Black
+12V2 2 6 COM Black
+12V2 3 7 COM Black
COM 4 8 COM Black
18AWG wire Signal Pin Pin Signal 22AWG wire
Yellow/Blue stripe
Yellow/Blue stripe
Yellow/Blue stripe
Black sense1
10. FAN SPEED CONTROL
Fan voltage varies with the ambient temperature or output power.
