49
ENGLISH
MULTI MEDIA SERVER MODE
---------------------------------------------------------------------
Playing the video, music and
image files with home network
connection
With DLNA menu of your television, you can
easily access Video, music and photo files on
server; and thanks to DMR feature, you can au-
tomatically start and stop media playing on de-
vices with DMC feature.
Notes:
7
You can share your video, music and image
files through devices such as PC, mobile
phone or NAS (Network Attached Storage)
that function as DMS (Digital Media Server)
compatible with DLNA.
7
If the DMS device and the TV are connected
to the wireless network at the same time,
there may be lags and freezings during
video playback.
7
TV can also operate with DMS software
that can be installed on a computer but,
it is not guaranteed that it will run in full
compatibility with software without a DMS
certificate.
7
Perform the following steps for a sample
DMS set up.
Open Windows Media Player11’i on a
computer with Windows operating system.
In »Library« tab, select »Media Sharing«,
tick on the »Share my media« box on the
window that appears and then select »OK«.
The new window displays the IP numbers
of connected devices. To enable the TV
to detect the computer, you need to select
the television‘s IP number. If IP is not listed
in the window; from »Media Sharing«
menu‘s »Settings« option, you can select the
option »Allow new devices and computers
automatically« in the pop-up menu. After
completing these processes, the television
can only view the supported file formats in
the Library.
In order not to encounter any problems with
media sharing, check the firewall settings of
your modem and computer.
Selecting the Digital Media Server
1 Open the »Select Source« menu with » «.
2 Select »DLNA« with »V«, »Λ«, »<« or »>«
and confirm with »OK«.
– »DLNA« menu is displayed.
Device Found 0
Page: 1/1
.Press BLUE key to search DMS device
3 Press »▯▯▯▯« (blue) to discover DMS devices
on home network.
– DMS devices that are discovered appears
in the menu.
Note:
7
If no DMS device appears, check the
network connection. See page 32 or 35.
4 You can select the DMS device you want
with »
V
«, »
Λ
«, »
<
« or »
>
« and see its
content with »OK«.
– The content appears.
Notes:
7
File and folder structure of the DMS device
in menu may vary depending on the Digital
Media Server software in use.
7
Subtitles are not supported on video files
that are played through the DMS device.
7
Video files played through DMS device
support following formats that have
obtained DLNA certificate: »MPEG_PS_
NTSC«, »MPEG_PS_PAL«, »MPEG_TS_
SD_EU« and »MPEG_TS_EU_ISO«.
7
In videos with high bit rate, lag problem
might be seen.
7
Folders that appear as unknown in DLNA
application cannot be played by the TV.
Installing the codec to your computer can
solve this problem.
