![SilverStone SX500-LG [5/12] Manual sx500 lg p180 v1 2](/views2/1719542/page5/bg5.png)
02
The power supply must meet inrush requirements for any rated AC voltage, during turn on at any phase
of AC voltage, during a single cycle AC dropout condition, during repetitive ON/OFF cycling of AC, and
over the specified temperature range. The peak inrush current shall be less than the ratings of its critical
components (including input fuse, bulk rectifiers, and surge limiting device).
2.3 Max. Input AC Current
Max. Input Current
7.0A
Measuring Range
90 - 264Vrms
2.4 Inrush Current
SST-SX500-LG provides an efficiency of 87% when measured at full load under 115V/60 and 230V/50Hz
condition.
2.5 Efficiency
Output
Voltage
+5V
+3.3V
+12V
-12V
+5Vsb
Load
MIN
0A
0A
0A
0A
0A
Range
MAX
20A
20A
40A
0.3A
3.0A
Peak
-
-
-
-
-
Regulation
±5%
±5%
±5%
±10%
±5%
Ripple
P-P Max.
50mV
50mV
120mV
120mV
50mV
Ripple & Noise
P-P Max.
50mV
50mV
120mV
120mV
50mV
3.1 Normal Operation Output
3. Output characteristics
Maximum continuous total DC output power should not exceed 500W.
Maximum continuous combined load on +3.3VDC and +5VDC outputs shall not exceed 105W.
Maximum combined load on 12V outputs shall not exceed 480W.
NOTE:
Noise test should be measured with 20 MHz bandwidth frequency oscilloscope. The output terminal
shall add a tantalum capacitor of 10uF in parallel with a ceramic capacitor of 0.1uF.
