Product description This instruction manual describes various appliance models General The hydraulically controlled flow through water heater is suitable for either an open depressurised or closed pressurised connection The flow through water heater continuously heats water while it flows through the appliance The appliance must not be operated with preheated water otherwise the overtemperature protection will be triggered These appliances are designed for permanent electrical connection ED6 2S high level appliance ED5 S U under counter appliances For the qualified engineer Preparation for installation For all appliances There must be a clearance of approximately 60 mm on all sides of the appliance for installation Observe the technical data for the appliance Flush the cold water supply line and shut it off Unscrew the screws on the housing cover and remove the lid Wall mounting For all appliances Secure the appliance using the installation template screws and wall plugs so that it is vertical and flush against the wall 1 Locate the appliance on the screw and press down 2 Screw in the second screw through the mounting tab and tighten For an exposed electrical connection the different methods of routing the supply line found on the assembly template must be observed The cable bushing must firmly enclose the connecting cable to ensure that it is protected against moisture In the event of damage seal the opening so that it is watertight 14
