Replacing the I/O board

WARNING: Before working inside your computer, read the safety

information that shipped with your computer and follow the steps in Before

working inside your computer. After working inside your computer, follow

the instructions in After working inside your computer. For more safety best

practices, see the Regulatory Compliance home page at

www.dell.com/

regulatory_compliance.

Procedure

1 Using the alignment posts, place the I/O board on the palm-rest assembly and

snap the I/O board into place.

2 Slide the I/O-board cable into its connector on the I/O board and close the latch

to secure the cable.

3 Replace the screw (M2x3) that secures the I/O board to the palm-rest

assembly.

Post-requisites

1 Follow the procedure from step 2 to step 8 in “Replacing the base cover”.

2 Replace the keyboard.

3 Follow the procedure from step 4 to step 5 in “Replacing the optical drive”.

4 Replace the battery.
