Bort BSS-1800-pet [12/28] Assembly and removal of dust barrel
![Bort BSS-1800-pet [12/28] Assembly and removal of dust barrel](/views2/1073253/page12/bgc.png)
12
PROTECTIVE DEVICES OF MOTOR
1. There is a temperature controller designed in the
body of cleaner motor, which can automatically cut
off the power supply of motor to prevent overheating.
When the air-inlet or air-outlet pipe is overloaded or
blocked, the temperature of motor rises, then the
temperature controller cuts off the power supply of
motor automatically to make the motor cool, preventing
the cleaner from being damaged.
2. If the temperature controller is cut off, stop the
cleaner immediately and pull out the power plug to
make the cleaner cool, and check and remove the
hair roll or other roll-like rubbish blocking the air inlet
(including the hose and the spile), and replace the fi lter
HEPA or fi lter gauze when necessary.
3. After cooling the motor for 30mins, plug in the power
plug and check whether the temperature controller has
been reset. If the power supply of the cleaner hasn’t
been cut off, the temperature controller of the motor
won’t be reset even when the motor has become cool.
MAINTENANCE OF THE CLEANER
All the day-to-day maintenance and repair jobs should
be done after the power plug has been pulled out.
2. Frequently remove the rubbish from the dust barrel,
so as to avoid the failure of the cleaner.
3. Never wipe the surface of the cleaner with gasoline
or oily liquid. Wipe it with water or neutral detergent.
Caution: be sure to wring out the wiping cloth dry for
wiping, it is prohibited for water to infi ltrate into electrical
elements of the cleaner.
3. When the cleaner is placed idle not in use, it should
not be put directly in the sun or in a damp place.
STORAGE OF THE CLEANER
1. Upon the completion of the operation of the cleaner,
turn off its power supply, and pull the power plug out of
the power socket, then step on the cord reeling button
to reel in the power cord fully. Hang the fl oor brush onto
the fl oor brush hook, as is shown in Figure (7).
1. Place the cleaner in the dry indoor environment.
CLEANING OF THE DUST BARREL
Remove the rubbish in the dust barrel frequently to
avoid the failure of the cleaner.
1. Clean the dust barrel only after the power plug of the
cleaner has been pulled out;
2. Put the dust barrel over the rubbish bin (bag), press
down the releasing button of the dust barrel, the bottom
cover of the dust barrel will automatically fall down, and
clear and empty the dust barrel, as is shown in Figure
(8).
ASSEMBLY OF HOSE
1. As is shown in Figure (3), insert the hose into the
duct inlet of the machine body in horizontal direction.
Please pay attention to the alignment of two projecting
parts. Turn the hose right when it is pushed into the
bottom, a click of inserting sound may be heard, i.e. the
hose is assembled into the machine body completely.
2. ASSEMBLY AND REMOVAL OF DUST
BARREL
As is shown in Figure (4), place the bottom of the dust
barrel on the projecting part at the front end of the
machine body, and press down the dust barrel. When
the front-end hook is entered into the corresponding
part of the machine body completely, and a click of
inserting sound is heard, which indicate that the dust
barrel is assembled in place. To remove the dust barrel,
press down the handle of the dust barrel; when the
handle is pressed down to the bottom, the dust barrel
can be lifted to remove.
ASSEMBLY OF METAL EXTENSION PIPE
AND FLOOR BRUSH
Insert the front end of the hose handle into the metal
extension pipe according to Figure (5); then insert
the other end of the metal extension pipe into the
rounded inlet of the fl oor brush, and adjust to the
proper direction. At this time, the assembly of the whole
machine is completed.
OPERATION INSTRUCTIONS
HOW TO START
1. First of all, pull out the power cord from the cord reel
to the needed length; insert the power cord plug into
the power socket, and press down the power switch
button with fi nger or step on it with foot; then you can
control the start and stop of the cleaner.
2. The yellow mark on the power cord indicates its
desired length. Never pull out the power cord to the
length exceeding the red mark.
CONTROL OF SUCTION FORCE
When the suction inlet is jammed by some cloth due
to the over-large suction force, you can adjust the air
escape pushbutton on the hose handle to control the
suction force at the suction inlet, as is shown in Figure
(6).
