18
БЕСПРОВОДНОЙ ПЫЛЕСОС
CORDLESS VACUUM CLEANER
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ • USER GUID
Packing details
Body
components
Hand-held
vacuum
cleaner
Support
frame
Electric brush
Combo
accessories
1
1
1
1
1
Installation of components
● Installation of Body components
Turn the handle until you hear a "click"
lock sound(figure 1)
●Connection of Electric brush
and the body components
When connecting, put the electric
brush on the groundfollowing the directions
shown in the illustration, put
the brush mounting hole under
the body component insert
vertically into the brush connector, and Press
the body components with force, until you
hear the "click" sound, thenthe installation is
completed (Figure 2)
●Connection of Hand-held vacuum cleaner and body
components
When installing the
hand-held vacuum
cleaner into the body
assembly, hold the
handle of the hand-held
vacuum cleaner and
insertinto the bottom
aiming to the square air
inlet of the body
assembly(Figure 3) ,
press the hand-held
cleaner in the direction
shown in the figure until
you hear the "lock" sound.
●Installation of vacuum cleaner and charging stand
Align the socket on the
back of the vacuum
cleaner with the support
plate on the cradle
assembly, installing as
shown in the illustration.
(Figure 4)
Notice：When stop
usingthe vacuum
cleaner, please put
the vacuum cleaner into the support frame timely, do not arbitrarily
put it on the wall or the edge of the chairto prevent unnecessary
damage due to falling caused by unstable place(Figure 5)
