21
БЕСПРОВОДНОЙ ПЫЛЕСОС
CORDLESS VACUUM CLEANER
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ • USER GUID
●Use of Flat suction and sofa suction
Put back the flat suction through pressing the brush
button in the direction of the figure, until the it is
stopped(Figure 6)
●Connection of combo accessories and
charging dock
Combo accessories can be placed in the support
frame when not use, insert it vertically into the
accessories bracket according to the figure (Figure 7）
●To remove the hand-held vacuum cleaner when used
alone,first hold down the
hand-held release
button, and then
remove hand-held
vacuum cleaner in the
direction of rotation as
shown in the figure.
(Figure 8)
●When storing or
cleaning the vacuum
cleaner, if you need to
disassemble the electric
brush, please hold down
the brush release button, and pull the electric brush
in the direction of the shown figure, then remove it
from the mounting hole. (Figure 9)
●If you need to store easily or need the fold handle
when cleaning the vacuum cleaner, please press the
handle release button (pictured) and turn the handle
in the direction shown in the figure. The handle can then be folded to the rear of
the body. (Figure 10)
Usage
Charging the vacuum cleaner
When the power of the vacuum cleaner is
low, please charge it timely; when the
voltage is too low, in order to protect the
battery, the vacuum cleaner will appear
automatically power-off protection
phenomenon, at this time the vacuum
cleaner must be charged. Before charging,
please ensure that the hand-held vacuum
cleaner and cradle assembly is installed
reliably. Plug the plug of the charging
power cord into the socket of AC power.
At this time, the charging indicator is
"circular flashing", indicating that the
vacuum cleaner is charging. (Figure 11)
After charging around 4 hours, when all
the three charging indicator lights are on,
it proves that the vacuum cleaner battery
is fully charged; the indicator lights will
automatically turn off three minutes after
fully charged, please pull out of the plug
in time from the AC outlet.
The vacuum cleaner features special charging hang-up function. In the charging
process of vacuum cleaner, when the charging indicator lights are flashing
recycling, the vacuum cleaner can not
start up even its switch button is pressed.
●Use of Flat suction and sofa suction
Put back the flat suction through pressing the brush
button in the direction of the figure, until the it is
stopped(Figure 6)
●Connection of combo accessories and
charging dock
Combo accessories can be placed in the support
frame when not use, insert it vertically into the
accessories bracket according to the figure (Figure 7）
●To remove the hand-held vacuum cleaner when used
alone,first hold down the
hand-held release
button, and then
remove hand-held
vacuum cleaner in the
direction of rotation as
shown in the figure.
(Figure 8)
●When storing or
cleaning the vacuum
cleaner, if you need to
disassemble the electric
brush, please hold down
the brush release button, and pull the electric brush
in the direction of the shown figure, then remove it
from the mounting hole. (Figure 9)
●If you need to store easily or need the fold handle
when cleaning the vacuum cleaner, please press the
handle release button (pictured) and turn the handle
in the direction shown in the figure. The handle can then be folded to the rear of
the body. (Figure 10)
Usage
Charging the vacuum cleaner
When the power of the vacuum cleaner is
low, please charge it timely; when the
voltage is too low, in order to protect the
battery, the vacuum cleaner will appear
automatically power-off protection
phenomenon, at this time the vacuum
cleaner must be charged. Before charging,
please ensure that the hand-held vacuum
cleaner and cradle assembly is installed
reliably. Plug the plug of the charging
power cord into the socket of AC power.
At this time, the charging indicator is
"circular flashing", indicating that the
vacuum cleaner is charging. (Figure 11)
After charging around 4 hours, when all
the three charging indicator lights are on,
it proves that the vacuum cleaner battery
is fully charged; the indicator lights will
automatically turn off three minutes after
fully charged, please pull out of the plug
in time from the AC outlet.
The vacuum cleaner features special charging hang-up function. In the charging
process of vacuum cleaner, when the charging indicator lights are flashing
recycling, the vacuum cleaner can not
start up even its switch button is pressed.
