iv
SAFETY TRAINING INFORMATION ������������ i
FOREWORD ����������������������� ii
IMPORTANT ����������������������� ii
EXPLICIT DEFINITIONS ����������������� ii
SUPPLIED ACCESSORIES ���������������� ii
PRECAUTION ���������������������� iii
TABLE OF CONTENTS ������������������ iv
1
PANEL DESCRIPTION ��������������� 1–5
n Panel description ������������������ 1
n Function display ������������������� 5
2
ACCESSORY ATTACHMENT ������������ 6–7
3
BASIC OPERATION ���������������� 8–11
n Setting a frequency ����������������� 8
n Setting a squelch level ���������������� 9
n Lock function �������������������� 9
n Receiving �������������������� 10
n Transmitting ������������������� 10
n Side tone function ����������������� 11
n LCD backlight ������������������� 11
n Low battery indicator ���������������� 11
4
MEMORY OPERATION �������������� 12–17
n Memory channel selection ������������� 12
n Memory bank selection (Available with the IC-A14 only) 12
n Programming a memory channel ���������� 13
n Memory names ������������������ 15
n Copying memory contents ������������� 16
n
Clearing the memory contents (Available with the IC-A14 only)
�������������������������� 17
5 SCAN OPERATION ���������������� 18–20
n Scan types �������������������� 18
n COM band scan ������������������ 18
n Memory scan ������������������� 19
n Weather channel scan (Available with the IC-A14 only) � 19
n “TAG” channel setting ��������������� 20
6
OTHER FUNCTIONS ��������������� 21–26
n Home function ������������������ 21
n Accessing 121.5 MHz emergency frequency
(Available with the IC-A14 only) ����������� 21
n Key touch beep tone ���������������� 22
n ANL function ������������������� 22
n Weather channel operation (Available with the IC-A14 only)
������������������������� 23
n Duplex operation (Available with the IC-A14 only) ��� 24
n Set mode setting ����������������� 25
7
BATTERY PACKS ���������������� 27–31
n Battery charging ������������������ 27
n Charging the battery ���������������� 29
8
CLONING �������������������� 32–33
9
TROUBLESHOOTING ���������������� 34
10
SPECIFICATIONS ������������������ 35
11
OPTIONS ��������������������� 36
12
OPTIONAL HEADSET CONNECTION ��������� 37
TABLE OF CONTENTS
