Icom IC-F50V [10/48] Panel description
![Icom IC-F50V [10/48] Panel description](/views2/1074193/page10/bga.png)
4
2
PANEL DESCRIPTION
■ Front, top and side panels
q VOLUME CONTROL [VOL]
Turns power ON and adjusts the audio level.
w RED BUTTON
The desired function can be assigned by your dealer. (p. 8)
e ANTENNA CONNECTOR
Connects the supplied antenna. (p. 2)
Microphone
Function display
(p. 6)
w
e
r
t
y
u
q
i
Speaker
! IC-F50V_F60V_0.qxd 07.8.6 10:36 AM Page 4 (1,1)
