Icom IC-F70DT [41/48] Options
![Icom IC-F70DT [41/48] Options](/views2/1074205/page41/bg29.png)
37
9
OPTIONS
D BATTERY PACK
• BP-235 Li-Ion
BATTERY PACK
7.4 V/1600 mAh Li-Ion battery pack, allows more than 8
hours operation. The same as supplied with the transceiver.
The BP-235 meets IPX waterproof specification grade 7.
• BP-236
Li-Ion
BATTERY PACK
7.4 V/2400 mAh Li-Ion battery pack, allows more than 12
hours operation.
The BP-236 meets IPX waterproof specification grade 7.
• BP-237
BATTERY CASE
Battery case for 6 × AA (LR6) alkaline cells.
The BP-237 meets IPX waterproof specification grade 4.
D CHARGERS
• BC-119N
DESKTOP CHARGER
+ AD-110
CHARGER ADAPTER
+ BC-145A
AC ADAPTER
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions. Charging
time: approx. 2.5 hours when BP-235 is attached.
•BC-121N
MULTI
-
CHARGER
+ AD-110
CHARGER ADAPTER
(6 pcs.)
+ BC-124
AC ADAPTER
For rapid charging of up to 6 battery packs (six AD-110’s are
required) simultaneously. An AC adapter should be pur-
chased separately. Charging time: approx. 2.5 hours when
BP-235 is attached.
D BELT CLIPS
• MB-93
SWIVEL BELT CLIP
• MB-94
BELT CLIP
The same as supplied with the transceiver.
• MB-96N/96F
LEATHER BELT HANGER
D OPTIONAL UNITS
• UT-109 (#02)/UT-110 (#02)
SCRAMBLER UNITS
Non-rolling type (UT-109)/Rolling type (UT-110) voice
scrambler unit provides higher communication security.
• UT-111
LTR TRUNKING BOARD
Provides trunking operation.
D DC CABLES
• CP-17L
CIGARETTE LIGHTER CABLE
Allows charging of the battery pack through a 12 V cigarette
lighter socket. (For BC-119N)
• OPC-515L/OPC-656
DC POWER CABLES
Allows charging of the battery pack using a 13.8 V power
source instead of the AC adapter.
OPC-515L: For BC-119N
OPC-656 : For BC-121N
• OPC-966
INTERFACE CABLE
Provides advanced operation, such as printer, GPS con-
nection for position data transmission capabilities during
BIIS operation.
8
9
IC-F70_F80-1.qxd 05.1.18 4:26 PM Page 37 (1,1)
