Icom IC-GM1600 [12/32] Basic operation
![Icom IC-GM1600 [12/32] Basic operation](/views2/1074256/page12/bgc.png)
7
BASIC OPERATION
4
■ Channel selection
D Channel 16
Channel 16 (Distress channel) is used for establishing initial
contact with another station and for emergency communica-
tions. While standing by, you must monitor Channel 16.
q Push [16] to select Channel 16.
w Push [CH] to return to the condition before selecting Chan-
nel 16, or push [Y]/[Z] to select the operating channel.
D Call channel
The call channels can be re-programmed (p. 9) and may be
used to store your most often used channels for quick recall.
q Push [CALL] to select the call channel.
•“CALL” and the call channel number appear.
• Call channel can be re-programmed. See the “Call channel
programming” on p. 9 for details.
w Push [CH] to return to the condition before selecting the
call channel, or push [Y]/[Z] to select the operating chan-
nel.
Push
Push
