Icom IC-V85 [16/80] Panel description
![Icom IC-V85 [16/80] Panel description](/views2/1074458/page16/bg10.png)
3
PANEL DESCRIPTION
2
■ Switches, controls, keys and connectors
q
!0
o
u
i
w
e
r
Speaker
Microphone
CONTROL DIAL
ANTENNA CONNECTOR
EXTERNAL SPEAKER/
MICROPHONE JACKS
FUNCTION DISPLAY
POWER KEY
EXTERNAL DC JACK
PTT SWITCH
UP/DOWN KEYS
KEYPAD
SQUELCH/MONITOR SWITCH
t
y
